Pressure Relief & Sustaining Valve
Free Delivery
Warranty
1 Year
Details
Specification
Model: SK730X
Set Pressure: ≤1.7
Set Pressure Difference: Ps＜0.5: ±0.014 MPa; Ps≥0.5: ±3%Ps
Open/Close Pressure Difference: Ps＜0.3: 0.06MPa; Ps≥0.3: 20%Ps
Discharge pressure: ≤1.2Ps
Description
SK730X Pressure Relief & Sustaining Valve is a diaphragm type of hydraulic control valve driven by the hydraulic pressure within the piping system. One prominent feature of the valve is, it can serve as pressure relief valve and sustaining valve at the same time. As pressure relief valve, it releases the high pressure before the valve out of the piping system for protection of the pipes and the equipment when the pressure exceeds its pre-set value; As pressure sustaining valve, it maintains the water pressure above certain set value for guarantee of water supply to upstream area.
