4” and 6” Sensor Base
Details
Specification
Approvals: UL Listed
Designed for use with all analog sensors.
Available in 4 and 6 inch models.
Contains a security locking tab for tamper protection.
Description
The VF7001 4” base and VF7002 6” base are designed for use with VES analog style sensors models VF2001, VF2002, VF2005, VF2003, VF2008, VF2010, VF2011 and VF2012.
Each base is connected to an Elite Signaling Line Circuit (SLC) and provides easy replacement of sensors, without disturbing the wiring. The bases are electronics free and contain a simple rugged design with screw terminals for wiring connections. A common mounting base allows sensor interchange and maintains loop continuity when sensors are removed. A simple anti-tamper
head Locking system is provided which is enabled by removing a small plastic tab on the back of the sensor. Once locked, the head can only be removed using a small diameter screw driver.
