Addressable Sounder & Flasher

Specifications

Part No.: UASF-I

Standard: EN54-3, EN54-23 and EN54-17

Operating Voltage: 15-32VDC

Isolator: Yes

Sound Level: Min: 89.4dB / Norm: 94.3dB / Max: 97dB ±2 dB (@27VDC, 1mt)

Protection Class: IP21C

Description

The UASF-I is a fire alarm sounder with a flasher for internal use that can be connected directly to a loop line. It features a built-in isolator
to protect the loop from shortcuts and can be powered by loop line. The UASF-I has 42 different tone settings and three different flasher
modes.
