Flanged Y-Type Strainer
Free Delivery
Warranty
1 Year
Details
Specification
Model: V4
Standard: UL Listed
Valve Body: ASTM A536, 65-45-12
Screen: AISI 304 (Perforated)
Gasket: Graphite + Acanthopore Plate
Bonnet: ASTM A536 65-45-12
Plug: Malleable Iron Galvanized Bronze ASTM B584
Bolt: Carbon Steel Zinc Plated AISI 304, AISI 316
Flat Washer: Carbon Steel Zinc Plated
Features
Connection Ends: Flange to ASME B16.1 CL 125
Working Pressure: 300PSI 200PSI and 250PSI available upon request
Temperature Range: -10℃- 200℃ graphite gasket 0℃- 80℃ rubber gasket
Coating: Fusion Bonded Epoxy Coating in accordance with ANSI/AWWA C550
