Lugged Wafer Butterfly Valve with Tamper Switch
Free Delivery
Warranty
1 Year
Details
Specification
Model: XD371XL
Standard: UL Approved
Valve Body: ASTM A536, 65-45-12
Disc: ASTM A536, 65-45-12
O-Ring: NBR
Stem: AISI 420, One-Piece Stem Design
Signal Gear Box: ASTM A536, 65-45-12
Features
Design Standard: MSS SP-67
Connection Ends: ASME B16.1 CL 125, ASME B16.5 CL 150
Top Flange Standard: ISO 5211 Stem drive by keys, parallel or diagonal square or flat head
Working Pressure: 250PSI 175PSI, 200PSI and 300PSI available upon request
Temperature Range: 0℃- 80℃
Coating: Fusion Bonded Epoxy Coating in accordance with ANSI/AWWA C550
